Polar Air WWP-V3 Wired Wallpad Controller

Polar Air WWP-V3 Wired Wallpad Controller

£99,999.00
£0.00 £99,999.00
Sale Sold out
Taxes included.
Brand logo

Product Overview: At a Glance

The Polar Air WWP-V3 Wired Wallpad is a sleek, touch-controlled interface designed for precise and reliable control of Polar Air fan coil units. Available in standalone and group control variants, it allows adjustment of temperature, fan speed, operating modes, valve operation, and louvre swing positioning. With an onboard room air temperature sensor, programmable scheduling, and integrated error display, the WWP-V3 provides clear and intuitive local control for a wide range of applications. Only available with I-Type Control - developed by Polar Air for intelligent control, I-Type Control and it’s controllers includes ADBS technology for ΔT management and group control.

Key Features & Benefits

  • Touch control screen with white backlight
  • Programmable 7-day ON/OFF timer
  • Fan speed control: Low / Medium / High / AUTO
  • Valve control: On/off or modulating, 2-way or 3-way / 6-way
  • Mode control: Cooling, Dehumidification, Heating, Ventilation, AUTO, Sleep mode
  • Louvre swing control
  • Key lock functionality
  • Onboard room air temperature sensor
  • Error display with addressable diagnostic
  • Temperature setpoint range: 16-30 °C (60.8-86 °F)

Typical Applications & Use Cases

The Polar Air WWP-V3 Wired Wallpad is suitable for a wide range of residential and commercial environments where compatible Polar Air units are installed. Some examples of such settings include the following:

  • Residential: Houses, apartments, student accommodation, assisted living
  • Hospitality: Hotel bedrooms, reception areas, restaurants, cafés
  • Education: Schools, colleges, universities, libraries
  • Commercial: Offices, banks, call centres, showrooms, server rooms

Technical Overview

The WWP-V3 range comprises two wallpad variants designed to suit different control requirements. The WWP-V3 provides one-to-one control of a single fan coil unit, while the WWP-V3-MS enables group control of up to 32 units from a single main wallpad.

Both models feature a flush or surface mounting design (model dependent), a backlit touch interface with key lock, and integrated error diagnostics that display fault type and unit address. Temperature control is supported across a 16–30 °C setpoint range, with multi-speed and automatic fan operation, valve control, selectable operating modes, and adjustable louvre swing positioning.

📄 View Specification Sheet
